Magnesia

Specialist for magnesium, rare earth and zirconium compounds

Under the trademark LUVOMAG® we pool a uniquely broad range of magnesia compounds and industrial minerals for many different applications and markets. The diversity of the possible applications reflects the width of our range of supply.

With our experience of 120 years we are a competent and reliable partner for our customers and prospects. We respond individually to customer and market requirements through applications engineering advice, supported by modern laboratory facilities and a constantly growing product portfolio.

Magnesium oxide

Our delivery program includes synthetic and natural magnesium compounds. You will find our standard grades below; further specialties are available.

LUVOMAG^® Magnesium oxide

Typical values

	Origin		Purity [wt %]					Activity		Other properties
Grade LUVOMAG^®	Syn.	Nat.	MgO ign.*	CaO	SiO₂	Fe₂O₃	LoI	BET [m²/g]	CAA pH 8.6	Particle size d₅₀ [μm]	Remarks
MO E1			90.6	1.7	2.6	0.2	5.0			< 74 μm
MO E3		•	93.3	1.7	1.5	0.2	3.2			< 40 μm
LUVOFLOOR®		•	93.1	3.0	6.5	0.4	2.4			10
MAGNULUV		•	94.1	2.5	4.0	0.35	4.3			8	High density
F-80 / F-100		•	92.0	2.5	3.5	0.6	4.0			< 75 / 63 μm	Milled grades
MO F-1		•	93.5	2.0	2.2	0.9	3.0		200	25
MO F-2		•	94.2	2.5	1.8	0.5	2.0		160	29
MO F-4		•	95.9	2.0	2.0	0.7	0.9			20
MO W-92		•	96.8	2.0	1.6	0.09	0.4		70	27
MO W-95		•	97.6	1.4	1.0	0.04	0.4		63	26
MO W-98		•	98.2	1.3	0.50	0.03	1.5		80	28
MO S-97		•	98.3	0.9	0.25	0.35	1.5		54	17
M 079	•		99.0	0.8	0.1	0.1	0.1	1		17	High density >1.000 g/l
M I	•		99.7	0.09	« 0,1	« 0,01	0,3	7		2
M 060	•		99.7	0.18	0.1	0.06	0.3	10		3
M 029	•		99.1	0.03	0.01	0.04	1.9	10		5
M 012	•		98.7	0.8	0.13	0.55	0.8	15		6
M 071	•		98.9	0.45		0.05		16		2
M H30	•		97.8	0.57		0.02		40		3
M 045	•		98.5	0.9	0.29	0.13	2.2	45		6
M 088	•		98.2	0.7	0.2	< 0.1	1.7
M 020	•		99.1	0.02	0.01	0.04	2.2	50		30
M 440	•		98.0	1.0	0.15	0.10	2.0	50
M 028	•		97.5	0.03		0.04		55		5
M E	•		99.2	0.6		< 0.01		70		5	Low density
M 072	•		98.5	0.5	0.12	0.04	3.5	100		3
M 075	•		98.6	0.5	0.12	0.04	4.1	105		4
M 047	•		98.5	0.9	0.27	0.13	4.1	106		7
M 476	•		97.6	1.0	0.17	0.09	6.0	125
B 150	•		98.0	1.1		0.05		130
M 474	•		97.6	1.0	0.20	0.11	5.9	140		3
N50^® / light	•		97.7	0.8		0.02	4.9	142		3	Low density
M SF	•		99.6			« 0.01		145		1
M 044	•		98.4	0.9		0.12		145		6
M 089	•		95.0	2.0		0.14		150		8
M 074	•		98.7	0.5	0.14	0.04	5.3	159		3
M 475	•		97.6	1.0	0.20	0.09	6.0	165		3
M 175	•		99.2	0.1		0.02		185		2

CAA: citric acid activity; *on ignited basis; LoI: loss on ignition.
Further grades available upon request.

According to the REACH Regulation (EC 1907/2006), magnesium oxide is exempt from registration (Annex V).
It does not contain intentionally added or relevant amounts of SVHC recently defined (published ECHA Candidate List:
echa.europa.eu/de/candidate-list-table ). Traces are possible. Since the presence of such substances in relevant
quantities cannot be expected under normal circumstances, Lehmann&Voss&Co. does not check for their absence.

Tailor-made solutions for the production of magnesia (Sorel) cement are also readiliy available.

	Origin	Purity [wt %]	Other properties
M 99	•		98.7	0.9	0.2	0.12	> 6 mm	Granular	Milled Grades
MO W-96		•	96.5	2.8	0.7	0.05	Various	Granular
MO W-94		•	95.5	3.1	0.7	0.03	Various	Granular
MO TA-12		•	96.5	1.7	0.5	0.1	48 μm d₅₀	Powder
MO TA-3		•	91.5	1.9	3.2	1.3	48 μm d₅₀	Powder
MO 9003		•	91.0	2.3	4.0	1.3	0 - 3 mm	Granular	Milled Grades

	Origin	Purity [wt %]	Other properties
FM E94		•	94.0	2.5	3.5	0.8	100 μm d₅₀	Powder	Electrical grade
FM E97		•	97.5	1.0	1.5	0.3	100 μm d₅₀	Powder	Electrical grade

Grade LUVOMAG^®	Mineral	Content [tw %]	Ash (%)	Density [g/l]	Remarks
270	MgO	70.0	70	1,900	Non-emigrating paste agent for rubber compounds
290	MgO	75.0	73	1,900	Non-emigrating paste agent for rubber compounds
300	MgO	60.0	59	1,900	Non-emigrating paste agent for rubber compounds
280	MgO	80.0	76	1,900	Non-emigrating paste agent for rubber compounds

	Origin	Purity [wt %]	Activity	Other properties
MO 50D		•	90.0	4.5	10.0	2.5	8.0			Gran	Var. sizes 0.1 - 1.5 mm
MO 54		•	90.5	3.5	2.5	1.5	3.5			Gran	Var. sizes 0.1 - 0.8 mm
MO F-2		•	94.2	2.5	1.8	0.5	2.0		160	29
MO F-4		•	95.9	2.0	2.0	0.7	0.9			20
MO S-97		•	98.3	0.9	0.25	0.35	1.5		54	17
M 060	•		99.7	0.18	0.1	0.06	0.3	10		3
M 088	•		98.2	0.7	0.2	< 0.1	1.7
M 020	•		99.1	0.02	0.01	0.04	2.2	50		30

Magnesium hydroxide

Our delivery program includes synthetic and natural magnesium compounds. You will find our standard grades below; further specialties are available.

LUVOMAG^® Magnesium hydroxide

Typical values

	Origin		Purity [wt %}
Grade LUVOMAG^®	Syn.	Nat.	Mg(OH)₂	CaO	SiO₂	Fe₂O₃	LoI	Remarks
H 002	•		99.2			0.02		BET 10 m²/g
H 015	•		99.0	0.45	0.12	0.04		BET 10 m²/g
H 110	•		96.5	0.70	0.10	0.07	31.5
H 257		•	95.3	2.1	3.7	0.50	31.0	Coated and var. milled grades available
Brucite		•	92.5	3.0	5.5	0.35	30.0	Various granular and milled grades available

Lol: loss on ignition.
Further grades and property details available upon request.

LUVOMAG^® Magnesium hydroxide.pdf

Food, nutrition and pharma grades

Please find information on this range of products here!

Magnesium carbonate

Our delivery program includes synthetic and natural magnesium compounds. You will find our standard grades below; further specialties are available.

LUVOMAG^® Magnesium carbonate

Typical chemical values

	Origin		Purity [wt %}					Other properties
Grade LUVOMAG^®	Syn.	Nat.	MgO*	CaO	SiO₂	Fe₂O₃	LoI	Particle size d₅₀ [μm]	Bulk density [g/l]	Remarks
C 430	•		40.0			0.02		6	135
C 060	•		40.0	0.45		0.02		40	690
C 025	•		42.0	0.32		0.01	54 %	2	165
C 019	•		42.6	0.17	0.03	0.05		6	310
C 400	•		42.8	0.75				40	440
C 014	•		43.0	0.31		0.03		6	80
C 013	•		43.8	0.25		0.003		8	120
MC 100		•	45.0	2.5	2.5	0.4	45 %	5
MC 500		•	45.0	2.5	2.5	0.4	48 %	45 / Gran
MC 200		•	45.5	2.4	2.9	0.1	46 %	5
MC 210		•	46.5	1.1	1.0	0.1	45 %	Gran		0-5 mm
Grip Cube		•	41.0					> 200	120	Sports chalk
Grip Chunk		•	41.0					> 200	120	Sports chalk

* On ignited basis.
Chemical composition: natural MgCO₃, synthetic 4MgCO₃·Mg(OH)₂·5H₂O.
Further grades and property details available upon request.

LUVOMAG^® Magnesium carbonate.pdf

Food, nutrition and pharma grades

Please find information on this range of products here!

Other Magnesium compounds

Our delivery program includes synthetic and natural magnesium compounds. You will find our standard grades below; further specialties are available.

LUVOMAG® Magnesium compounds

Typical values

		Origin		Purity [wt %}
Grade LUVOMAG^®	Mineral	Syn.	Nat.	Content	Fe₂O₃	Remarks
S 700	Sulphate: MgSO₄ anhydrous	•		98.7	0.002	Powder
S 900	Sulphate: MgSO₄ anhydrous	•		98.5	0.01	Powder
S 800/801	Sulphate: MgSO₄ anhydrous		•	98.5		Powder d₅₀ 300μm
S 770	Sulphate: MgSO₄ x 7 H₂O	•		99.7	0.001	Granulate
S 880/881	Sulphate: MgSO₄ x 7 H₂O		•	99.0	« 0,001	Powder d₅₀ 900μm
MGCL	Chloride: MgCL₂ x 6 H₂O		•	46.8		Flakes; AF grade available
NO3-99	Nitrate: Mg(NO₃)₂ x 6 H₂O	•		99.8	< 0.001	Granulate
